VHM-HPC-Alu-Fräser mit Schutzeckenradius, lang
E.7750.1L
Geeignet für Material
(Anklicken für Materialeignung)P
Allgemeine Baustähle/Automatenstähle
| Material | <500 N/mm² | <700 N/mm² | <850 N/mm² | <1000 N/mm² | <1400 N/mm² |
|---|---|---|---|---|---|
| Eignung |
P
Vergütungsstähle
| Material | <850 N/mm² | <1000 N/mm² | <1400 N/mm² | >1400 N/mm² |
|---|---|---|---|---|
| Eignung |
M
Rost- und säurebeständige Stähle
| Material | <700 N/mm² | >700 N/mm² |
|---|---|---|
| Eignung |
K
Gusseisen und Gusseisenlegierungen
| Material | Gusseisen bis 180 HB | Temper-<br>guss | Gusseisen mit Kugel-<br>graphit |
|---|---|---|---|
| Eignung |
N
Ne-Metalle, Kunststoffe, Graphit
| Material | AL & AL-Legierungen bis 6% Si | AL & AL-Legierungen unter 12% Si | AL-Legierungen über 12% Si | Kupfer, Messing, Bronze, Rotguss | Kunststoff- Thermoplaste | Kunststoff- Duroplaste | GFK/CFK | Graphit |
|---|---|---|---|---|---|---|---|---|
| Eignung |
|
|
|
|
|
|
S
Sonderlegierungen & Titan
| Material | Inconel, Hastelloy, Nimonic, Monel | Titan |
|---|---|---|
| Eignung |
H
Gehärteter Stahl
| Material | 45-55 HRC | 55-60 HRC | 60-65 HRC |
|---|---|---|---|
| Eignung |
| Artikel-Nr. |
|
|
|
|
|
|
|
auf Lager | Anfrage | Alternativen |
|---|---|---|---|---|---|---|---|---|---|---|
|
E.7750.1L.0600
|
6 | 0.2 | 5.5 | 80 | 13 | 42 | 6,0 |
|
||
|
E.7750.1L.0600.050
|
6 | 0.5 | 5.5 | 80 | 13 | 42 | 6,0 |
|
||
|
E.7750.1L.0600.100
|
6 | 1 | 5.5 | 80 | 13 | 42 | 6,0 |
|
||
|
E.7750.1L.0600.150
|
6 | 1.5 | 5.5 | 80 | 13 | 42 | 6,0 |
|
||
|
E.7750.1L.0600.200
|
6 | 2 | 5.5 | 80 | 13 | 42 | 6,0 |
|
||
|
E.7750.1L.0800
|
8 | 0.25 | 7.5 | 100 | 21 | 58 | 8,0 |
|
||
|
E.7750.1L.0800.050
|
8 | 0.5 | 7.5 | 100 | 21 | 58 | 8,0 |
|
||
|
E.7750.1L.0800.100
|
8 | 1 | 7.5 | 100 | 21 | 58 | 8,0 |
|
||
|
E.7750.1L.0800.150
|
8 | 1.5 | 7.5 | 100 | 21 | 58 | 8,0 |
|
||
|
E.7750.1L.0800.200
|
8 | 2 | 7.5 | 100 | 21 | 58 | 8,0 |
|
||
|
E.7750.1L.1000
|
10 | 0.3 | 9.5 | 100 | 22 | 62 | 10,0 |
|
||
|
E.7750.1L.1000.050
|
10 | 0.5 | 9.5 | 100 | 22 | 62 | 10,0 |
|
||
|
E.7750.1L.1000.100
|
10 | 1 | 9.5 | 100 | 22 | 62 | 10,0 |
|
||
|
E.7750.1L.1000.150
|
10 | 1.5 | 9.5 | 100 | 22 | 62 | 10,0 |
|
||
|
E.7750.1L.1000.200
|
10 | 2 | 9.5 | 100 | 22 | 62 | 10,0 |
|
||
|
E.7750.1L.1200
|
12 | 0.3 | 11.5 | 120 | 26 | 73 | 12,0 |
|
||
|
E.7750.1L.1200.050
|
12 | 0.5 | 11.5 | 120 | 26 | 73 | 12,0 |
|
||
|
E.7750.1L.1200.100
|
12 | 1 | 11.5 | 120 | 26 | 73 | 12,0 |
|
||
|
E.7750.1L.1200.150
|
12 | 1.5 | 11.5 | 120 | 26 | 73 | 12,0 |
|
||
|
E.7750.1L.1200.200
|
12 | 2 | 11.5 | 120 | 26 | 73 | 12,0 |
|
||
|
E.7750.1L.1600
|
16 | 0.4 | 15.5 | 150 | 36 | 98 | 16,0 |
|
||
|
E.7750.1L.1600.100
|
16 | 1 | 15.5 | 150 | 36 | 98 | 16,0 |
|
||
|
E.7750.1L.1600.150
|
16 | 1.5 | 15.5 | 150 | 36 | 98 | 16,0 |
|
||
|
E.7750.1L.1600.200
|
16 | 2 | 15.5 | 150 | 36 | 98 | 16,0 |
|
||
|
E.7750.1L.1600.250
|
16 | 2.5 | 15.5 | 150 | 36 | 98 | 16,0 |
|
||
|
E.7750.1L.2000.150
|
20 | 1.5 | 19.5 | 150 | 41 | 100 | 20,0 |
|
||
|
E.7750.1L.2000.200
|
20 | 2 | 19.5 | 150 | 41 | 100 | 20,0 |
|
||
|
E.7750.1L.2000.250
|
20 | 2.5 | 19.5 | 150 | 41 | 100 | 20,0 |
|
||
|
E.7750.1L.2000.300
|
20 | 3 | 19.5 | 150 | 41 | 100 | 20,0 |
|
||
|
E.7750.1L.2000.400
|
20 | 4 | 19.5 | 150 | 41 | 100 | 20,0 |
|
