Geeignet für Material
(Anklicken für Materialeignung)P
Allgemeine Baustähle/Automatenstähle
| Material | <500 N/mm² | <700 N/mm² | <850 N/mm² | <1000 N/mm² | <1400 N/mm² |
|---|---|---|---|---|---|
| Eignung |
|
|
|
|
|
P
Vergütungsstähle
| Material | <850 N/mm² | <1000 N/mm² | <1400 N/mm² | >1400 N/mm² |
|---|---|---|---|---|
| Eignung |
|
|
|
M
Rost- und säurebeständige Stähle
| Material | <700 N/mm² | >700 N/mm² |
|---|---|---|
| Eignung |
|
|
K
Gusseisen und Gusseisenlegierungen
| Material | Gusseisen bis 180 HB | Temper-<br>guss | Gusseisen mit Kugel-<br>graphit |
|---|---|---|---|
| Eignung |
|
|
|
N
Ne-Metalle, Kunststoffe, Graphit
| Material | AL & AL-Legierungen bis 6% Si | AL & AL-Legierungen unter 12% Si | AL-Legierungen über 12% Si | Kupfer, Messing, Bronze, Rotguss | Kunststoff- Thermoplaste | Kunststoff- Duroplaste | GFK/CFK | Graphit |
|---|---|---|---|---|---|---|---|---|
| Eignung |
|
|
|
|
|
|
|
S
Sonderlegierungen & Titan
| Material | Inconel, Hastelloy, Nimonic, Monel | Titan |
|---|---|---|
| Eignung |
|
H
Gehärteter Stahl
| Material | 45-55 HRC | 55-60 HRC | 60-65 HRC |
|---|---|---|---|
| Eignung |
| Artikel-Nr. |
|
|
|
|
auf Lager | Anfrage | Alternativen |
|---|---|---|---|---|---|---|---|
| E.3601.0.0020 | 0.2 | 30 | 2 | 1,0 |
|
||
| E.3601.0.0023 | 0.23 | 30 | 2 | 1,0 |
|
||
| E.3601.0.0025 | 0.25 | 30 | 2 | 1,0 |
|
||
| E.3601.0.0030 | 0.3 | 30 | 2.5 | 1,0 |
|
||
| E.3601.0.0035 | 0.35 | 30 | 4 | 1,0 |
|
||
| E.3601.0.0040 | 0.4 | 30 | 4 | 1,0 |
|
||
| E.3601.0.0042 | 0.42 | 30 | 4 | 1,0 |
|
||
| E.3601.0.0045 | 0.45 | 30 | 6 | 1,0 |
|
||
| E.3601.0.0050 | 0.5 | 30 | 6 | 1,0 |
|
||
| E.3601.0.0057 | 0.57 | 30 | 6 | 1,0 |
|
||
| E.3601.0.0058 | 0.58 | 30 | 6 | 1,0 |
|
||
| E.3601.0.0060 | 0.6 | 30 | 6 | 1,0 |
|
||
| E.3601.0.0065 | 0.65 | 30 | 7 | 1,0 |
|
||
| E.3601.0.0070 | 0.7 | 30 | 7 | 1,0 |
|
||
| E.3601.0.0072 | 0.72 | 30 | 7 | 1,0 |
|
||
| E.3601.0.0075 | 0.75 | 30 | 8 | 1,0 |
|
||
| E.3601.0.0076 | 0.76 | 30 | 8 | 1,0 |
|
||
| E.3601.0.0080 | 0.8 | 30 | 8 | 1,5 |
|
||
| E.3601.0.0082 | 0.82 | 30 | 8 | 1,5 |
|
||
| E.3601.0.0085 | 0.85 | 30 | 8 | 1,5 |
|
||
| E.3601.0.0090 | 0.9 | 30 | 8 | 1,5 |
|
||
| E.3601.0.0095 | 0.95 | 30 | 10 | 1,5 |
|
||
| E.3601.0.0100 | 1 | 30 | 10 | 1,5 |
|
||
| E.3601.0.0105 | 1.05 | 30 | 10 | 1,5 |
|
||
| E.3601.0.0110 | 1.1 | 30 | 10 | 1,5 |
|
||
| E.3601.0.0115 | 1.15 | 30 | 12 | 1,5 |
|
||
| E.3601.0.0120 | 1.2 | 30 | 12 | 1,5 |
|
||
| E.3601.0.0123 | 1.23 | 30 | 12 | 1,5 |
|
||
| E.3601.0.0125 | 1.25 | 30 | 12 | 1,5 |
|
||
| E.3601.0.0130 | 1.3 | 30 | 12 | 1,5 |
|
||
| E.3601.0.0132 | 1.32 | 30 | 12 | 1,5 |
|
||
| E.3601.0.0142 | 1.42 | 30 | 12 | 1,5 |
|
||
| E.3601.0.0145 | 1.45 | 30 | 12 | 1,5 |
|
||
| E.3601.0.0150 | 1.5 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0155 | 1.55 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0160 | 1.6 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0165 | 1.65 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0167 | 1.67 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0169 | 1.69 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0170 | 1.7 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0175 | 1.75 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0180 | 1.8 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0185 | 1.85 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0190 | 1.9 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0195 | 1.95 | 30 | 12 | 2,0 |
|
||
| E.3601.0.0200 | 2 | 30 | 12 | 2,5 |
|
