Suitable for material
(Click for material suitability)P
General construction steel / free machining steel
| Material | <500 N/mm² | <700 N/mm² | <850 N/mm² | <1000 N/mm² | <1400 N/mm² |
|---|---|---|---|---|---|
| Suitability |
|
|
|
|
|
P
Heat treatable steel
| Material | <850 N/mm² | <1000 N/mm² | <1400 N/mm² | >1400 N/mm² |
|---|---|---|---|---|
| Suitability |
|
|
|
|
M
Rust and acid constant steels
| Material | <700 N/mm² | >700 N/mm² |
|---|---|---|
| Suitability |
|
|
K
Cast iron and cast iron alloy
| Material | Cast iron until 180 HB | Metallable cast iron | Cast iron with nodular graphite |
|---|---|---|---|
| Suitability |
|
|
|
N
Non-ferrous metal, plastics, graphite
| Material | Aluminium und AL-alloyed until 6% Si | Aluminium und AL-alloyed (under 12% Si) | Aluminium alloyed over 12% Si | Copper, brass, bronze, red brass | Plastics - thermoplast | Plastics - duroplast | GFK/CFK | Graphite |
|---|---|---|---|---|---|---|---|---|
| Suitability |
|
|
|
|
|
S
Special alloy and titanium
| Material | Inconel, Hastelloy, Nimonic, Monel | Titanium |
|---|---|---|
| Suitability |
H
Hardened steel
| Material | 45-55 HRC | 55-60 HRC | 60-65 HRC |
|---|---|---|---|
| Suitability |
| Product-Nr. |
|
|
|
|
|
in stock | Request | Alternatives |
|---|---|---|---|---|---|---|---|---|
| E.2640.0.0050 | 2 | 0.5 | 25 | 2,3 - 2,6 | 3,15 |
|
||
| E.2640.0.0080 | 2.5 | 0.8 | 25 | 2,6 - 2,9 | 3,15 |
|
||
| E.2640.0.0100 | 2.9 | 1 | 31 | 3,0 - 3,3 | 3,15 |
|
||
| E.2640.0.0125 | 3.15 | 1.25 | 31 | 3,3 - 3,6 | 3,15 |
|
||
| E.2640.0.0160 | 4 | 1.6 | 35 | 4,2 - 4,7 | 4,00 |
|
||
| E.2640.0.0200 | 5 | 2 | 40 | 5,0 - 5,4 | 5,00 |
|
||
| E.2640.0.0250 | 6.3 | 2.5 | 45 | 6,3 - 6,8 | 6,30 |
|
||
| E.2640.0.0315 | 8 | 3.15 | 50 | 8,0 - 8,5 | 8,00 |
|
||
| E.2640.0.0400 | 10 | 4 | 55 | 10,0 - 10, | 10,00 |
|
||
| E.2640.0.0500 | 12.5 | 5 | 63 | 12,5 - 13, | 12,50 |
|
||
| E.2640.0.0630 | 16 | 6.3 | 71 | 16,0 - 16, | 16,00 |
|
||
| E.2640.0.0800 | 20 | 8 | 80 | 20,0 - 20, | 20,00 |
|
||
| E.2640.0.1000 | 25 | 10 | 100 | 25,0 - 25, | 25,00 |
|
||
| E.2640.0.1250 | 31.5 | 12.5 | 125 | 31,5 - 32, | 31,50 |
|
